Overview
Area Sizing Estimating Table
Light Commercial Perc-Rite Selection Table
| Package # | Description | Zone Detail | Material List | Filter Unit | Control Panel |
|---|
| ASD153-D124 | 15 gpm, 3 Zone w/ Duplex 2 Filter, 4-Zone Control Panel | 3 ZONE LAYOUT | ASD153-D124 | ASD15 3 ZONE HU LINE DRAWING | DP0 2 FILTER DUPLEX 4 ZONE CONTROL |
| ASD154-D124 | 15 gpm, 4 Zone w/ Duplex 2 Filter, 4-Zone Control Panel | 4 ZONE LAYOUT | ASD154-D124 | ASD15 4 ZONE HU LINE DRAWING | DP0 2 FILTER DUPLEX 4 ZONE CONTROL |
| ASD151-D126 | 15 gpm, 6 Remote Zone w/ Duplex. 2 Filt., 6- Zone HMI Control | 6 ZONE LAYOUT | ASD151-D126 | ASD15 1 ZONE HU LINE DRAWING | DP2 2 FILTER DUPLEX 6 ZONE CONTROL |
| ASD151-D128 | 15 gpm, 8 Remote Zone w/ Duplex. 2 Filt., 8-Zone HMI Control | 8 ZONE LAYOUT | ASD151-D128 | ASD15 1 ZONE HU LINE DRAWING | DP2 2 FILTER DUPLEX 8 ZONE CONTROL |
| ASD251-D124 | 25 gpm, 4 Remote Zone, W/Duplex 3 Filter 4-Zone HMI Control | ASD25 4 ZONE | ASD251-D124 | ASD25 HU LINE DRAWING | DP2 3 FILTER DUPLEX 4 ZONE CONTROL |
| ASD251-D126 | 25 gpm, 6 Remote Zone, W/Duplex 3 Filter 6-Zone HMI Control | ASD25-6 ZONE | ASD251-D126 | ASD25 6 ZONE | AS SPECIFIED |
| ASD251-D128 | 25 gpm, 8 Remote Zone, W/Duplex 3 Filter 8-Zone HMI Control | ASD25-8 ZONE | ASD251-D128 | ASD25 8 ZONE | AS SPECIFIED |
| ASD251-D1212 | 25 gpm, 12 Remote Zone, W/Duplex 3 Filter 12-Zone HMI Control | ASD25-12 ZONE | ASD251-D1212 | ASD25 12 ZONE | AS SPECIFIED |
| ASD251-D1216 | 25 gpm, 16 Remote Zone, W/Duplex 3 Filter 16-Zone HMI Control | ASD25-16 ZONE | ASD251-D1216 | ASD25-16 ZONE | AS SPECIFIED |
| ASD251-D1220 | 25 gpm, 20 Remote Zone, W/Duplex 3 Filter 20-Zone HMI Control | ASD25-20 ZONE | ASD251-D1220 | ASD25-20 ZONE | AS SPECIFIED |
| ASD251-D1224 | 25 gpm, 24 Remote Zone, W/Duplex 3 Filter 24-Zone HMI Control | ASD25-24 ZONE | ASD251-D1224 | ASD25-24 ZONE | AS SPECIFIED |
